Sarracenia Spiketail
(Cordulegaster sarracenia)
(note: unlike my other pages, with newest photos first, I will maintain this
page sequentially, as it documents the discovery of a species new to science)
2010
These photos represent what is apparently an undescribed species of Spiketail
from the Longleaf Pine region of deep east Texas. These specimens were
photographed on 16 & 17 April 2010. The male pictured first was found at
approximately 10:25 am on the 16th patrolling a stream trickle in a sunny
pitcher plant bog on the slopes at the back of Boykin Springs Lake in northern
Jasper County. Both Dad (Terry Hibbitts) and I got a nice series of
photos. Initially, we thought it was just an aberrant Twin-spotted
Spiketail (Cordulegaster maculata), with a bit more ringed pattern.
However, this specimen was smaller than is typical for that species (at probably
just over 2") and the eyes do not touch at the top of the head, which is
characteristic in that species (only noticed when we examined the photos).
The second specimen was photographed on 17 April 2010 at 11:26 a.m. on an
overcast morning. It was found foraging in a fire-managed longleaf pine
area on a ridge within a couple hundred meters of a nearby pitcher plant seep.
This location is approximately 0.5 mile to the N of the initial location.
It was immediately apparent that the female shared the ringed pattern with the
male. Also immediately noticeable was that its subgenital plate
("ovipositor") did not extend beyond the S10 abdominal segment. Also
visible in the photos was the fact that eyes did not touch. This female
appeared to be even smaller than the male.
When I got home, I posted my trip list to the TexOdes listserv, and mentioned
that I had photographed 2 abberant "Twin-spotted Spiketails", one of which was a
female with "an abnormally short ovipositor". Shortly after posting,
Dennis Paulson emailed back suggesting that I look more closely, as the length
of the subgenital plate ("ovipositor") varied very little within a particular
species of Spiketail, and that Twin-spotteds possessed very long ovipositors.
Upon re-examination of the photos , the nearest I could come to
similar species were the Brown Spiketail (C. bilineata) and Say's Spiketail (C.
sayi), neither of which occur near to Texas (both east of the Mississippi
River). However, this insect appears smaller than both, and its coloration
and pattern combines features with both species (brown like C. bilineata
and ringed much like C. sayi), as well as having features that they lack
(most noticeably the blue eyes). I emailed photos to Dennis Paulson, John
Abbott, Greg Lasley, and Martin Reid pointing out these differences and
suggesting that they must "either be abberant Brown Spiketails or 'something
new'". Paulson emailed me back and suggested that "something new" was most
likely.
TEXAS: Jasper Co; Angelina National Forest, near Boykin Springs Lake - male - 16
April 2010
31.063495°N, 94.279479°W
TEXAS: Angelina Co; Angelina National Forest, ca 0.7 mi N of Boykin Springs Lake -
female - 17 April 2010
31.071453°N, 94.277070°W (approximate)
Upon receipt of the photos, Abbott almost
immediately cut short a trip to the Lower Rio Grande Valley, driving from Starr
County to Jasper in order to attempt to collect a specimen. On Wednesday,
4/21/10, the group (John Abbott, Nick Donnelly, Greg Lasley, and Martin Reid)
were successful in netting a male at the seep above Boykin Springs Lake.
On Thursday, 4/22/10, Dad joined them and took them to the seep area off the
Radio Tower Road north of Boykin Springs, and they were able to locate and
photograph a female, which escaped netting. Later that same day, a male
was located in the same area, and was successfully collected.
I took off work on Friday, and drove over the night of 4/22 to spend 4/23-25
searching the area for another specimen. I was met by rains on 4/23,
although it cleared off by late afternoon. Dad & I did see two Arrowhead
Spiketails (C. obliqua) but none of the new species. On Saturday,
4/24, I searched the area all morning, then joined Taylor Hall and Scott
Wahlberg to search the Scrappen Valley site in Newton Co. Although the
habitat looked promising, I was only able to locate a single specimen of
Arrowhead Spiketail (C. obliqua) - this was a new county record. On
4/25, I started my search at the Boykin Springs seep. Found another
promising seep nearby, but located no spiketails at either site. Searched
a seep near the Red-cockaded Woodpecker trail on the Boykin Springs road, and
located a female Arrowhead Spiketail (barely into Angelina Co, also a new county
record). Finally, on a desperate last gasp search, I returned to the Radio
Tower road, and shortly spotted a female of the new spiketail flying down the
road, which I was able to successfully net and collect for a specimen.
TEXAS: Angelina Co; Angelina National Forest, ca 0.8 mi N of Boykin Springs Lake
- female - 25 April 2010
31.07361°N, 94.27974°W
collected and donated to Texas Natural History Collection
Interesting, two independent photo records have been submitted to Odonata
Central of this species - one was found at the Gus Engling Wildlife Management
Area in Anderson County by Gary Spicer on 4/12/10. The other was found on
the Big Thicket Preserve's Pitcher Plant Trail in southern Tyler County on
3/29/09 by Rick Nirschl. The Spicer specimen was "uncovered" by Martin
Reid searching the OC database - it had been misidentified as a Twin-spotted
Spiketail. Nirschl emailed me directly, and pointed out that he had found
a similar animal the year before. Nirschl indicated that he had been
convinced that he'd found something undescribed, but that his photos of a single
male specimen had not convinced Paulson and Abbott that it was anything more
than an unusual somewhat ringed variant of the Twin-spotted Spiketail, and his
specimen went mis-identified as
Twin-spotted Spiketail for a year, but with collection of specimens
and our more extensive series of photos, the photos of the Nirschl and Spicer
specimens have been re-evaluated.
See also Greg Lasley's account of their search
here, as well as
Martin Reid's account
here.
2011
In March 2011, we resumed the search for this new species. I decided to
start my search in similar habitats in Louisiana's Kisatchie National Forest.
I began my spring break vacation by searching the Vernon Unit of the Kisatchie
NF in Vernon Parish, Louisiana. On 13 March I searched bogs in the western
portion of the National Forest, and found Bog JD 240, Drake's Creek South Bog,
and LSU Area Bog 6-3a to possess seemingly suitable habitat, but discovered no
Cordulegaster of any species. 14 March was rainy, but I met with
Steve Shively (FS Biologist) and we searched Cooter's Bog for about an hour
before the storm arrived. Cooter's also possesses seemingly suitable
habitat, but weather conditions all but eliminated Odonate activity (we saw 1
Mantled Baskettail and 1 Variegated Meadowhawk before the rain began to fall).
I then drove to the Middle Branch Bog in the Kisatchie District in Natchitoches
Parish, mostly to check out the site, and found it to be a beautiful hillside
bog, very similar to, but far more extensive than, similar bogs in the Boykin
Springs Area.
15 March 2011 was scheduled to be my last day of efforts in Louisiana, and I
again met Steve Shively at Cooter's Bog. We searched there for 2 1/2
hours, but found no Spiketails. I then left to go back to Middle Branch
Bog, where I searched from 3:00-6:30 pm. There, I discovered a teneral
male of the species, as well as observed 2 other, more mature specimens which I
was unable to photograph or net. The not only represent the fourth known
locale for this species, but also the first records of it for the state of
Louisiana as well as the earliest date on record for the species (ties with a
specimen collected the same day by John Abbott and Greg Lasley at Boykin
Springs). Here is the series of photos of the Louisiana State Record for
the "New Texas" spiketail.
LOUISIANA: Natchitoches Parish; Kisatchie National Forest, Middle Branch Bog -
teneral male - 15 March 2011
31.48353°N, 93.07568°W
On 16 March 2011, we were scheduled to meet with my parents at Boykin Springs,
so Marla, Cheyenne, and I searched that area from just before noon until about
5:30 pm. Intermittent clouds limited ode activity at times, but we were
able to photograph and collect a female specimen approximately 400 meters west
of the type locality for this new species on the pipeline cut near Boykin
Springs Lake.
TEXAS: Jasper Co; Angelina National Forest, Boykin Springs Recreation Area -
young female - 16 March 2011
31.05983°N 94.28390°W
Tripp Davenport observed a young male at the type locality bog, while Abbott and
Lasley photographed another young female at a location about 1 mile west of the
Boykin area. Marla & I also observed an adult male
Twin-spotted
Spiketail near the pipeline bog.
On 17 March 2011, Dad & I met up with Taylor Hall, who had obtained access for
us at Temple Inland's Scrappin' Valley Research Forest. Last year, I had
searched Scrappin' Valley with Taylor, and found several well maintained bogs
with limited surface water. Although I wasn't sure that the habitat was
suitable, I felt that there was a good chance that there might be a population
of the new species in the area. Within an hour of our arrival, Dad was
able to net a young female specimen similar to the one I had photographed on 16
March. This specimen represents the 5th known locale for this species.
TEXAS: Newton Co; Temple Inland Scrappin' Valley Research Forest - female - 17
March 2011 (new county record)
31.13940°N, 93.79774°W
We also had several tantalizing fly-by's that may have been this species, as
well as observed at least 3 different
Twin-spotted
Spiketails. Abbott & Lasley also collected a specimen at the type
locality on the pipeline cut at Boykin Springs.
On 18 March 2011, Dad, Marla, and I met with John Abbot, Greg Lasley, and Steve
Shively at Middle Branch Bog. Dad was able to photograph a young female,
and we also had 1 definite and 1 tentative fly-by. Meanwhile, Steve
Shively's son found a teneral female on the bog, and the group collected a
mostly mature male on the bog. As I walked up to the bog to grab a bit to
eat at the truck, Marla alerted me that the group was photographing a spiketail
on the bog RIGHT NOW! We got a good series of photos, and even got one
with the bug photographed perched on a pitcher plant.
LOUISIANA: Natchitoches Parish; Kisatchie National Forest, Middle Branch Bog -
male - 18 March 2011
(note: the small yellow flecks on his thorax are pine pollen)
We then went to check out nearby bogs, and found spiketail at another bog within
a mile of Middle Branch. A third bog was fairly dry and didn't produce any
sightings, and the fourth bog on my list was overgrown an completely unsuitable.
LOUISIANA: Natchitoches Parish; Kisatchie National Forest, FR Bog near Middle
Branch - male - 17 March 2011
31.48698°N 93.06547°W
On April 9, 2011, I again spent a day searching the bogs on the Vernon Unit for
spiketails. I did have 2 fly-bys by other spiketail species (1
Twin-spotted Spiketail, C. maculata, and 1 Arrowhead Spiketail, C.
obliqua), but did not see any of the new species. I also searched bogs
on Mayhaw Ridge in the southern portion of the Kisatchie Unit. Habitat
here is probably suitable for the new species, but I did not see any
individuals. Late in the afternoon, I went up to Middle Branch Bog to
photograph the site and was able to locate a single female specimen.
Midde Branch Bog, site of what is likely the largest population of the new
spiketail species
LOUISIANA: Natchitoches Parish; Kisatchie National Forest, Middle Branch Bog -
female - 9 April 2011
10 April 2011 found me back at Middle Branch Bog in the morning, hoping to find
a mating pair of the new species, but was unsuccessful. I did
however find 3 different individuals - 2 males and 1 female. Windy
conditions made those dragonflies that were active very sedentary, and I was
able to take extreme close-up shots with my macro lens of all 3 specimens that I
found.
LOUISIANA: Natchitoches Parish; Kisatchie National Forest, Middle Branch Bog -
male 1 - 10 April 2011
LOUISIANA: Natchitoches Parish; Kisatchie National Forest, Middle Branch Bog -
female - 10 April 2011
LOUISIANA: Natchitoches Parish; Kisatchie National Forest, Middle Branch Bog -
male 2 - 10 April 2011
Later in the afternoon, I again searched the Mayhaw Ridge sites but was only
able to locate a single
Arrowhead
Spiketail (C. obliqua). On 11 April 2011, I spent part of the
morning searching the Boykin Springs area, but it was very overcast and
threatening rain. I again found only a single
Arrowhead
Spiketail (C. obliqua), this one a teneral male. Interestingly,
as far as I am aware, the specimens I found this weekend were the last specimens
seen in 2011.
The species description was published in May 2011 in Zootaxa:
Abbott, John C. & Troy D. Hibbitts. 2011. Cordulegaster
sarracenia, n. sp. (Odonata: Cordulegastridae) from east Texas and
western Louisiana, with a key to adult Cordulegastridae of the New World.
Zootaxa 2899: 60-68.
pdf copy available on request.
2012
In 2012, I committed to train for and run a Marathon with my wife (Marla), and
was unable to spend much time in East Texas or Louisiana searching for
Spiketails. Spiketail sightings this spring were few and far in between
due to the drought. To the best of my knowledge, no adult specimens were
found this year in the Boykin Springs area, although nymphs were collected
there. Dad found a single male at a new location on the Sabine/Newton Co
line, for the 6th verified locality for the species.
Easter Weekend, I took a break from training and running, and met John & Kendra
Abbott, Greg Lasley, Ed Lam, and Mike Dillon in the Kisatchie National Forest.
Ed had made the trip down from New York to collect a male and female specimen
for his forthcoming Peterson Field Guide to the Dragonflies of North America.
Before meeting up with them, I searched bogs on Mayhaw Ridge but found no
spiketails. I then joined them at Middle Branch Bog, where we found
several individuals, one of which was extremely cooperative and allowed a series
of photos (by Ed, Greg, Mike, and myself).
LOUISIANA: Natchitoches Parish; Kisatchie National Forest, Middle Branch Bog -
male - 7 April 2012
We searched the area from about 10:00 am until about 2:00 pm. After
finishing up there, I stopped to look for
Harlequin Darners (Gomphaeschna furcillata) at a locale I'd found
them the year previously and managed to net 2 males (but did not find any
naturally posed - except on that landed on my leg). I then searched the
Mayhaw Ridge bogs again, but found only a single
female
Twin-spotted Spiketail (C. maculata). This site has now yielded
2 of 3 species of Spiketail, just not any Sarracenias.
